VOXAURA Clamp-on-glass Linear Light, PL4004, 24V, 5W/m, 2-pin Multi-white, 2700-5000K, 640 LEDs/m, IP20, 3m, Silver-grey

Documentation
Brochure
Product description

The PL4004 clamp-on-glass linear light is designed for 6 mm glass shelves. Its pre-assembled 3 m aluminium profile contains a COB LED ribbon and diffuser, providing adjustable 2700–5000 K white light at 24 V and 5 W/m. With CRI 93 and 640 LEDs per metre, it delivers 205 lm/m. The light is rated IP20 and supports dimming with compatible controls.

The profile can be cut to the required length on site, then connected using clip-on end components and a power cable. Supplied as one linear light with the diffuser pre-installed. Installation and connection accessories are sold separately.

Specifications and selection

SKU 201.11.22.012

  • Colour System: Multi-white, 2-pin
  • Colour Temperature: 2700 - 5000K
  • Kind of Light: Clamp-on-glass Linear Light for 6mm glass
  • Colour Rendering Index Ra: 93
  • Luminous Flux: 205 lm/m
  • Lumen Efficacy: 41 lm/W
  • Dimensions (LxWxH): 3000 x 22 x 11 mm
  • Colour / Finish: grey
  • Material: aluminium
  • Number of LEDs: 640/m
  • Input Voltage: 24 V DC
  • Wattage: 5 W/m
  • Beam Anngle: 120°
  • with Sensor: no
  • Energy Efficiency Class: G
  • Degree of Protection: IP20
  • Installation: surface mounting

Select the matching SKU and dimensions for your installation. Contact KnoxOne if you need help confirming the configuration.

Product features
SKU
201.11.22.012
Colour System
Multi-white, 2-pin
Colour Temperature
2700 - 5000K
Kind of Light
Clamp-on-glass Linear Light for 6mm glass
Colour Rendering Index Ra
93
Luminous Flux
205 lm/m
Lumen Efficacy
41 lm/W
Dimensions (LxWxH)
3000 x 22 x 11 mm
Colour / Finish
grey
Material
aluminium
Number of LEDs
640/m
Input Voltage
24 V DC
Wattage
5 W/m
Beam Anngle
120°
with Sensor
no
Energy Efficiency Class
G
Degree of Protection
IP20
Installation
surface mounting
